Super Coil Kit - 4-cyl - Universal
Caracteristicas: High-output coils for use in 2 cylinder motorcycles ACCEL engineers designed these coils' special low-resistance primary winding to match the operating characteristics of factory and aftermarket CDI systems Maximum performance with fast rise times Extra-heavy-duty 8.8mm silicone wires included Made in the U.S.A. Using the wrong coil may damage your motorcycle's electronic ignition module. To determine your ignition type, complete the following test: 1. Determine whether the type of coil you are replacing is a high tower coil. (These coils will NOT replace single tower coils.)2. Using a volt meter or 12V test light, hook the positive lead to the positive post and the negative lead to the ground on one of the stock coils.3. Turn the ignition on, but DO NOT engage the starter button.4. If there are 12V at the coil, the motorcycle has an inductive type ignition. If there is no voltage at the coil, then the motorcycle has a CDI ignition because the power goes to the control box first.
Peso: 4.3
Alto: 2.33
Largo: 11.65
Ancho: 6.37
Aditamentos:Specs:Ignition Type: Electronic (Capacitor Discharge)
Riding Style: Street
Ignition Fire Method: Dual
Input Voltage: 12 V
Units: Kit
Color/Finish: Black
Model: Super Coil
Style: External
Type: Ignition
Electrical Resistance: 3.0 Ohms
Product Name: Coil
Peso: 4.3
Alto: 2.33
Largo: 11.65
Ancho: 6.37
Aditamentos:Specs:Ignition Type: Electronic (Capacitor Discharge)
Riding Style: Street
Ignition Fire Method: Dual
Input Voltage: 12 V
Units: Kit
Color/Finish: Black
Model: Super Coil
Style: External
Type: Ignition
Electrical Resistance: 3.0 Ohms
Product Name: Coil
