Caracteristicas:

The ultimate ATV chain, developed to withstand the severe stresses of ATV riding, yet lightweight with maximum performance

QUAD chains feature the patented Z44 sealing rings, which greatly improve performance and wear life, making previous X-ring and Z-ring chains obsolete

50% reduction in friction compared to traditional O-rings

Constant lubrication from special high-temperature grease in the critical pin/bushing area provides long life

High-carbon alloy pins to minimize wear and increased roller thickness to prolong durability

Thicker outer plates and quad-riveting for greater tensile strength

All parts are shot-peened for maximum fatigue resistance, and all chains are pre-loaded for superior performance and minimal adjustment

Suitable for ATVs up to 900cc

8,093 ft./lbs. tensile strength

Gold color

Peso: 4.43
Alto: 1.14
Largo: 10.94
Ancho: 5.03
Aditamentos:Specs:Color/Finish: Gold
Master Link Connector: Clip
Maximum Engine Displacement (Offroad): 500 cc
Model: Quad Series
Number of Links: 96
Tensile Strength: 8091 lb
Chain Size: 520
Riding Style: UTV
Seal Type: Z44-Ring
Tensile Strength: 36 kN (8091 lb)
Tensile Strength: 36 kN
Weight: 1,76 kg/100 Links
Chain Type: 520 QUAD
Product Name: Drive Chain
Riding Style: ATV
Units: Each
